5.1 Pin assignment
The drawing alongside shows the pin assignment of the lockable NL4 mounting connector
(1+/1–).
Drawing and table indicate the pin assignment of 1/4" TS phone plugs to be used.
1 Signal
2 Ground
NL4 mounting connector for
speaker connection
Phone plugs for signal in and
outputs
Connections and operating elements
active full-range speaker
18
