Page 26 Transforma
™
Ladder User Manual
Using the Transforma
™
Ladder
Spreader Bar Attachment
IMPORTANT: The spreader bar attachment must be used for the 120Kg
model when using when using the 120Kg model in the A-frame position.
Step Action
1 Rotate the front forks on the work platform to the horizontal
position.
Forks
Fork Bolt
2 Select the third rung down and insert the top rail of the semi-
circle brace into the top slot on the back of the rung.
3 Then insert the 2 front forks into the top slot on the rung on
the opposite side.
