The Singing Machine SML625BTW - Location of Controls (Front); Front Panel Controls and Indicators

— E3 —
Location of Controls (Front)
1. CDG/USB/BT Button
2. PROGRAM/REPEAT
Button
3. Skip Back 9 Button
4. AUTO VOICE CONTROL
Button
5. BLUETOOTH PAIRING
Button
6. BLUETOOTH indicator
7. ON/OFF Button
8. SKIP 10- Button (MP3)
9. BALANCE Control
10. USB Port
11. LINE IN Jack
12. MASTER VOLUME
Control
13. Play/Pause Button
14. Stop < Button
15. Skip Forward : Button
16. MIC VOLUME control
17. RECORD Button
18. Record Indicator
19. DISCO LIGHT Button
20. Skip10+ Button (MP3)
21. ECHO Control
22. Mic Holder
23. Mic 2 jack
24. Mic 1 jack
25. Speaker
26. CDG Indicator
27. Play/Pause Indicator
28. Program Indicator
29. Repeat Indicator
w
v
x
y
U
V
u
X
WW
at
ak
al
am
an
ao
ap
aq
ar
as
bt
bk
bl
bm
bo
bn
bp bq
br bs
Display
Lense
