The Source SOURCE04BLP - Rotisserie Motor Installation and Operation; Installing the Rotisserie Motor and Spit

Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. On your
grill the Motor attaches to the Bracket with the electrical cord DOWN, not up. This installation insures
that Rotisserie Motor is slid onto Motor Bracket and Stainless Steel Spit must be inserted into the
Motor.
4.
The bushing and collar must always be used with this Rotisserie.
Insert the assembled Rotisserie into the Motor as shown below. The Motor should be on the right side
of your grill and the Handle on the left side. Place the Bushing into the slot opening on the left side
of your grill bowl, then tighten the Collar Thumbscrew to the right of the Bushing. The Collar will stabilize
the Rotisserie during the cooking process and the Bushing allows the Rotisserie Spit to turn smoothly.
Plug the Rotisserie into an outlet and turn on to test.
BEFORE rotisserie cooking you will need to remove the Cooking Grid(s) and possibly the Flame Tamers
from your grill. When rotisserie cooking place a Cooking Pan under the food to be cooked. This will capture
the drippings and keep your grill clean of excess grease which could cause a fire. Use caution when
moving a Cooking Pan containing hot oils.
5.
Handle
Bushing
Collar
Thumbscrew
Holding Forks
Thumbscrew
Spit
GRILL BOWL
28
Spit must be
inserted into
the Motor
Rotisserie Motor with
electrical cord DOWN
Motor Bracket
