The Source SOURCE04BLP - Page 6

6
The following table illustrates a breakdown of the hardware pack. It highlights what components are used
in the various stages of assembly.
Contents for Hardware Pack/LPG (Part #P06020003A)
Install Cart Side Panel, Caster Seat and Cart
Bottom Shelf
Attach Caster Seat to Cart Bottom Shelf
Attach Cart Side Panel to Cart Rear Panel
Attach Door Handle Bracket to Doors
Attach Door Bracket to Cart Side Panel
Attach Tank Pull-Out Tray Assembly and Tank Pull-
Out Tray Stop to Cart Bottom Shelf
Attach Side Burner Frame and Side Shelf to Bowl
Attach Handle Brackets to Side Burner and Side
Shelf
Attach Bowl to Cart
Attach Tool Holder/Towel Rack to Side Burner
Frame/Side Shelf and side of Control Panel
Install Cart Towel Rack and Spice Basket
Power the Electric Ignitor
Power the Fuel Gauge
Tighten the Caster
S112G04401
S313G04061
S112G04081
S112G04081
S112G04081
S112G04081
S112G04081
S112G04081
S112G04081
S142G04161
S112G03081
S172G03081
P05301001A
P05301002A
P05515005A
Phillips Head Screw 1/4"x2"-1/2"
Flange Nut 1/4"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Phillips Head Screw 1/4"x1/2"
Countersink Flat Head Screw 1/4"x1"
Phillips Head Screw 3/16"x1/2"
Self-Tapping Screw 3/16"x1/2"
Battery/AA
Battery/AAA
Wrench
Ref.
Purpose of Components
8
8
8
4
8
4
6
8
8
6
2
6
2
2
1
Qty.Component
Battery/AA
Qty. 2
Ref. # P05301001A
Countersink Flat Head Screw 1/4"x1"
Qty. 6
Ref. # S142G04161
Phillips Head Screw 1/4"x2-1/2"
Qty. 8
Ref. # S112G04401
Phillips Head Screw 3/16"x1/2"
Qty. 2
Ref. # S112G03081
Flange Nut 1/4"
Qty. 8
Ref. # S313G04061
Phillips Head Screw
1/4"x1/2"
Qty. 46
Ref. # S112G04081
Size and Quantity of each Hardware Piece:
LPG MODEL ONLY
Wrench (scale: 1/2)
Qty. 1
Ref. # P05515005A
Battery/AAA
Qty. 2
Ref. # P05301002A
Self-Tapping Screw
3/16"x1/2"
Qty. 6
Ref. # S172G03081
