4.1 Pin assignment
XLR mounting sockets are provided for signal inputs. XLR mounting plugs are provided for
signal outputs. The figure and the table show the XLR pin assignment for balanced wiring.
1 Ground
2 Positive signal (+)
3 Negative signal (–)
XLR-connections for signal in-/
outputs
Installation and operation
digital speaker management system
12
