7 Jog wheel
The jog wheel can be used to set parameters, enter values and select menu options.
8 LED-display input channel A / B
The LEDs show the signal strength of the input signal. Reduce the output level of the device connected to the
affected channel in the event of overdrive ("CLIP" LED flickers or is permanently lit).
9 LED-display output channel 1 to 4 with MUTE switch
The LEDs show the signal strength of the output signal. In the event of overdrive ("CLIP" LED flickers or is perma‐
nently lit), reduce the output level of the affected channel. The MUTE switch can be used to mute the channels indi‐
vidually; in this case, the associated display LED lights up.
10 Mains switch to activate/deactivate the device.
Connectors and controls
DS 2/4
15
