Range Meaning
Display area Shows the current configuration of input to output channels.
Output and input channels can be renamed. Click on a function area (e.g. ‘GEQ’ or ‘DELAY’) to open
the tab in which you can directly enter the corresponding parameters.
Control area By clicking with the mouse you can connect any input channel to any output channel. Each output
channel can be freely assigned to one input channel or a mix of several input channels. The input
channels with a green background are assigned to the respective output channel. You can set a level
adjustment for any combination of input and output channel.
“Matrix” tab
Control on the computer
DSP 204, DSP 206, DSP 306, DSP 408
25
