• Do not operate in the presence of flammable anesthetic mixtures, oxygen, or nitrous oxide.
• Do not operate the unit without the plastic grate on the bottom.
• Do not touch the bottom or sides of the metal tank, or a burn may result.
• Do not heat paraffin on a stove, hotplate, or in a microwave.
• Do use this appliance on a level, secure surface.
• Do not use any additives in the paraffin except as allowed by the manufacturer.
• Do not modify this equipment without authorization from the manufacturer.
• Care must be taken when operating this equipment around other equipment. Potential electromagnetic
or other interference could occur to this or the other equipment. Minimize this interference by not
using other equipment in conjunction with it.
Cautions
• Do not remelt used paraffin, reintroduced particles or chemicals may damage the tank.
• Never use sharp objects to remove hardened paraffin from the unit.
• Do not leave an empty unit plugged in.
• Do not pour melted paraffin from the tank.
NOTE: The emissions characteristics of this equipment make it suitable for use in industrial areas and
hospitals (CISPR 11 class A). If it is used in a residential environment (for which CISPR 11 class B is normally
required) this equipment might not offer adequate protection to radio-frequency communication services.
The user might need to take mitigation measures, such as relocating or re-orienting the equipment.
Technical Information
• Power, Model TB6: 100–125V, 0.87–1.3A, 50–60Hz
• Power, Model TB7: 220–240V, 0.55–0.65A, 50–60Hz
• Heater: TB6: 87–162 watts, TB7: 121-156 watts
• Operating temperature: 126º–134º F. (52.2º–56.7º C.)
• 14.3” L x 8.2” W x 7.5” H (36.32 cm L x 20.83 cm W x 19.1 cm H)
• Capacity: 9 lbs. (4.08 kg.)
• Melt time: 6-8 hours
• Duty cycle: continuous operation
• Degree of protection against moisture ingress: IPX0
• 220V unit must be used with a hospital grade cord of at least the maximum ratings: 10 A, 220 VAC.
• Meets IEC/EN 60601-1-2:2014 electromagnetic compatibility interference safety standard.
Environmental Ratings
Operating Transport and Storage
Temperature: 65° to 85° F (18.3° to 29.4° C) -40° to 130° F (-40° to 54.4° C)
Relative Humidity: 10% to 95% 10% to 95%
Atmospheric Pressure: 70 to 160 kPa 70 to 160 kPa
NOTE: “Hospital Grade” grounding
reliability can only be achieved when
the equipment is connected to
an equivalent receptacle marked
“Hospital Only” or “Hospital Grade”
NOTE: Current and wattage
must be measured at operating
temperature.
No. Test/Standard Port (enclosure,
AC, DC, I/O)
Emissions Class and Group /
Immunity Test Level
1 CISPR 11, Radiated Emissions Enclosure Class A; Group 1
2 IEC 61000-4-2 Enclosure ±8kV contact, ±2kV, ±4kV, ±8kV, ±15kV air
3 IEC 61000-4-3 Radiated RF
Immunity
Enclosure 3V/m, 80-2700MHz, 80% 1kHz AM
4 IEC 61000-4-3 Proximity fields from
RF wireless equipment
Enclosure Section 8.10 of the IEC 60601-1-2 standard
5 IEC 61000-4-4 AC 2kV, 100kHz repetition rate
6 IEC 61000-4-5 AC Line-to-Line: ±0.5 kV, ±1 kV
Line-to-Ground: ±0.5 kV, ±1 kV, ±2 kV
7 IEC 61000-4-6 AC 3V, 0.15-80MHz, 80% 1kHz AM, 6V in ISM Band
within 0.15-80MHz, 80% 1kHz AM
8 IEC 61000-4-8 Enclosure 30A/m, 50Hz and 60Hz¬
9 IEC 61000-4-11 Voltage Dips AC 0% (100% reduction), 0.5 cycle; 0% (100% reduction),
1 cycle; 70% (30% reduction) UT, 0.5 sec
10 IEC 61000-4-11 Voltage Interruptions AC 0% (100% reduction), 5 sec
