Assembly
Connect the remaining male cord from the main unit to the female outlet
on the motor/speed controller unit. Plug the male power cord of the control
unit into the surge protector, and the surge protector into the GFI protected
outlet. Protect these exposed cords with cord protectors.
Be sure both cord retainer doors are closed and then carefully lay both units
back down on to the leveling feet at the same time.
Bolt Plates
Next install the bolt plates. which are located near the middle of the unit
on both sides between the TheraPlate logo stickers , one on each side of
the unit. using a 9/16” wrench or socket, remove the two bolts in the half
without the bolt plate, then loosen the two bolts holding the bolt plates in
place, about 3/4 of the way out, pull the bolt plate away from the unit and
rotate it 180 degrees and line up and reinsert the two bolts removed in the
first step. Tighten all four bolts until they are tight.
Continued overleaf…
Never plug the TheraPlate directly into any power source. failure to use
the TheraPlate motor/speed controller will result in permanent damage
to the motors, and the resulting damage is not covered by the warranty.
