Assembly
Save these instructions
We highly recommed that the unit be placed out of the weather, on rubber
mats on a solid surface (asphalt, concrete, etc).
If the TheraPlate must be located in a stall, be sure it is on clean rubber
mats with no shavings. The area under and around the base of unit must be
kept clean and free of debris. be sure to protect the unit from flooding from
neighboring stalls and any other potential sources of water intrusion.
Your TheraPlate arrives in two 80 pound sections. Each section has flush
cut rubber on one end and rubber that overhangs on the other end. this is
a protective feature to protect the feet & legs of the horse as they enter
or depart the machine. when setup properly, the flush cut ends should be
together in the middle with only a very small gap between the units.
Place the units on their side with the carry handles facing up. Open the cord
retainer boxes on the bottom of each unit. The main unit has a male and
female power cord, the secondary unit has a single male power cord.
Pull the female cord out of the main unit and connect to the male cord in the
secondary unit. Important - the cords should not be pushed back past the
back side of the cord retainer box.
If the cord(s) are pushed past the back of the retainer box, the cord could be
lost inside the unit. this connection should then be closed and remain inside
the secondary unit cord retainer box, as shown in the picture below. This
cord connection will remain inside the secondary unit cord retainer box.
