Item checklist
1. Heater with a bracket 1 pc
2. Bracket mounting screws 4 pcs
3. Mounting screw plugs 4 pcs
4. Mounting screw for support legs 8pcs
5. Operation manual 1 pc
6. Support legs 2 pcs
INSTALLATION INSTRUCTIONS
Wall mounting the heater
1. Remove all packaging material from the product.
2. Determine the place to install heater, observing minimum distances from objects
and minimum distance from the floor (refer to diagram below).
Precaution! This heater is suitable for use in bathrooms, only when it is fixed wall
mounted. The location must be within accordance to AS/NZS 3000.
This heater, having an IPX4 rating, MUST only be mounted within zone 2 and 3 (refer to
diagram above) of the bathroom outline in section 6.2, of AS/NZS 3000: 2007, and
positioned so that the control panel and power switches cannot be touched by a
person in the bath or shower in zone 1.
3. Mark the height at which the heater is to be mounted and then place the
bracket onto the wall.
Heater Diagram
1. Control Panel
2. Outlet grill louver
3. Unit case
4. Support legs
5. Cold air inlet
