TR2 1000W PSU TR2 1000W PSU
ATX12V 2.2 & EPS 12V 2.91 Version
Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply
ATX12V 2.2 & EPS 12V 2.91 Version
0807
Floppy Disk Connector (4 pin)
Peripheral Connector (4 pin)
CPU Connector (4 pin)
1
4
Color Signal Pin
Black COM 1
Black COM 2
Yellow +12V 3
Yellow +12V 4
Color Signal Pin
Yellow +12V 1
Black COM 2
Red +5VDC 4
Black COM 3
Color Signal Pin
Yellow +12V 4
Black COM 2
Red +5VDC 1
Black COM 3
Yellow
+12V
1
Black COM 2
Red +5VDC 3
Black COM 4
Orange +3.3VDC 5
Color Signal Pin
Serial ATA Power Connector
8 pin PCI-E to 6 pin PCI-E Converter
Enable 8pin PCI-E connector connect to the graphic card
that only has 6pin PCI-E socket.
20+4pin Main Power
4+4pin CPU Power
4 pin CPU Power
Peripheral & Floppy
S-ATA
6 pin standard PCI-E
6 pin standard PCI-E
8 pin standard PCI-E
8 pin standard PCI-E
Connector +12V1 +12V2 +12V3 +12V4
W0176 - 1000W PSUW0176 - 1000W PSU
+12V Rail Distribution
170 X 140 mm170 X 140 mm
