Thermaltake TR2 - TR2 1000 W PSU Specification

>> >>>> >>
TR2 1000W PSU TR2 1000W PSU
ATX12V 2.2 & EPS 12V 2.91 Version
Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply
ATX12V 2.2 & EPS 12V 2.91 Version
1009
Model
W0176
SPECIFICATION
Power
Dimension
Switches
PFC
Cooling System
Efficiency
INPUT
Input Voltage
Input Frequency Range
MTBF
Input Current
Hold-up Time
1000W
140mm(L)x150mm(W)x86mm(H)
ATX Logic on-off additional power rocker switch
Active PFC (PF > 0.9)
120mm ball-bearing Fan
3100 RPM 10%
Typical load of 80% at 115V / 230V input
Typical Load 20ms
115 VAC- 230 VAC
47 ~ 63 Hz
100,000 hrs minimum at 25 C
14.5A - 7.5A
OUTPUT
Max/Min
Regulation
Ripple & Noise
Output
+12V1
+12V3
+12V2
+5V
+3.3V
-12V
+5Vsb
Total Power
1000W
30A/0.8A +5,-5%
75mV
175W
975W
25W
75mV
140mV
140mV
140mV
200mV
75mV
+5,-5%
+5,-5%
+5,-5%
+5,-5%
+10,-10%
+5,-5%
30A/0.5A
20A/0.5A
20A/0.5A
20A/0.5A
1.0A/0.0A
3.0A/0.1A
ENVIRONMENT
Operating Temp.
Storage Temp.
Operating Humidity
Storage Humidity
10 to 50
-20 to 80
5% to 95%, non-condensing
5% to 95%, non-condensing
PROTECTION
DC rail
Trigger Point/Range
Over Voltage Protection
Over Current Protection
Short Protection All output to GND
+3.3V trip point
+5.0V trip point
+12.0V trip point
+3.3V
+5.0V
+12V
30A Max.
48A Max.
60A Max.
13.5V~16.5V
3.76V~4.8V
5.6V~7.0V
Peak Power
1100W(3S)
+12V4
140mV
+5,-5%
20A/0.5A
Voltage
Items
4.2 TR2 1000W Specification PSU
24-pin
Main Connector
8-pin
+12V Power
Connector
4-pin
Peripheral Power
Connector
4-pin
Floppy Drive
Connector
6-pin
PCI Express
Connector
Total Output Connector
X1 X1
X1
X6 X1
5-pin
SATA Connector
Technology Features
X10
- Four +12V Rails
- EPS Structure
X2 X2
X2
- Hi-Tech Black housing
- Intelligent temperature control 120mm Fan
Ten S-ATA
Connectors
4-pin
+12V Power
Connector
8-pin
PCI Express
Connector
8-pinto 6-pin
PCI Express
Connector
AC INPUT
DC OUTPUT
Maximum Load
Minimum Load
Max Combined
Wattage
The continuous total output power is 1000W, peak 1100W(3 sec.)
Total combined +12V output load shall be 75A.
110V-240V 13-6.5A 50-60Hz
175W
975W 25W
+3.3V
+5V
+12V1 +12V2
+12V3
+12V4 -12V
+5VSB
30A 30A
20A 20A 20A 20A
1A
3A
0.8A 0.5A 0.5A 0.5A 0.5A 0.5A 0.0A 0.1A
Performance
170 X 140 mm170 X 140 mm
W0176_TR2_1000W_ _A07102201
