TR2 1000W PSU TR2 1000W PSU
ATX12V 2.2 & EPS 12V 2.91 Version
Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply
ATX12V 2.2 & EPS 12V 2.91 Version
4.4 Protection:
If the power supply protection that latch off all main outputs. ( when
OCP, OVP or short protection is working ).Reset by cycling remote
on/off control or AC power.
4.4.1 Over Current Protection
4.4.2 Over Voltage Protection
+3.3V output
+5.0V output
+12.0V output
4.4.3 Short Protection
All output to GND.
3.76V ~ 4.8V
5.6V ~ 7.0V
13.5V ~ 16.5V
4.5 Environment:
4.5.1 Operating Temp. +10 C to +50 C
4.5.2 Storage Temp. -20 C to +80 C
4.5.3 Operating Humidity 5% to 95%, non-condensing
4.5.4 Storage Humidity 5% to 95%, non-condensing
4.6 EMI & Safety
12
11
+3.3V
+5.0V
+12V
Trigger Point
60A Max.
48A Max.
30A Max.
Output Voltage
4.6.1 EMI Regulatory
- FCC Part 15 Subpart J, class 'B'
- CISPR 22 Class 'B'
4.6.2 Safety
- NEMKO EN60950
- VDE EN60950
- CSA C22.2 NO.60950
- IEC 60950
- UL 60950
- CE
4.3.1 Inrush Current:
Maximum inrush current from power-on (with power on at any
point on the AC sine) and including, but not limited to, three
line cycles, shall be limited to a level below the surge rating of
the input line cord, AC switch if present, bridge rectifier, fuse,
and EMI filter components. Repetitive ON/OFF cycling of the
AC input voltage should not damage the power supply or
Cause the input fuse to blow.
4.3.2 Power Efficiency:
4.3.3 Note:
The combined power of +5V and +3.3V is 175W max.
Add 0.1uF and 10uF capacitors across output terminal during
ripple & noise test.
4.3.4 Hold-Up Time:
20mSec. minimum at typical load
4.3.5 Power Good Delay:
100-500 msec.
4.3.6 Power Fail Delay:
>1 msec.
4.3.7 Rise Time:
20ms max at full load.
4.3.8 MTBF at 25 C(demonstrated)
100KHrs minimum
4.3 Other Specification
Loading Full load Typical load Light load
115V Required Minimum Efficiency 76% 80% 80%
230V Required Minimum Efficiency 80% 80% 80%
170 X 140 mm170 X 140 mm
