Thermann T2F136S - Specifications for 250 L to 400 L Models

7
THM0421 026512 Rev. E
Thermann Owner’s Manual
80L to 400L Electric Storage Water Heaters
Nominal Dimensions
Tank Size 250L 315L 400L
Total Height (A) 1445 1765 1705
Total Diameter (B) 620 620 705
Outlet Height (C) 1210 1530 1445
Inlet Height (D) 195 195 220
Electrical Entry (E) 105 105 130
Top Sensor (F) 770 865 830
Solar Return (G) 565 555 545
Bottom Sensor (H) 355 350 350
Flow (J) 195 195 220
Element Angle (K) 70° 70° 70°
Specifications - 250L to 400L
Specifications
Tank Size
250L 315L 400L
Storage Capacity (L) 259 321 415
Hot Water Delivery (L) 250 315 400
Net Weight Empty (kg) 72 93 115
Element(s) Sizes (kW) 3.6 3.6 3.6
Relief Valve:
Pressure (kPa) 1000 1000 1000
Temperature (°C) 99 99 99
Power Rating (kW) 10kW 10kW 10kW
