ThermaQ Evocyl - Cylinder Connections Overview

3
CYLINDER CONNECTIONS
Hot Water Draw Off
Cold Inlet
Secondary Return
(where fitted)
Heating Flow (Zone 2)
Heating Flow (Zone 1)
Balanced Cold
Expansion Vessel
Tundish Discharge
Heating Return
Return To Boiler
Flow From Boiler
Twin Zone Cylinder Depicted
For Illustration Purposes Only
