THERMEX VERTICAL ATOMATIC
35
• This hood has been developed and produced in accordance with DS/
EN 60335-1.
• This hood is only suitable for use in private households; any other
use will invalidate the warranty.
• All installations must be carried out by a qualified technician in ac-
cordance with the instructions set out by Thermex Scandinavia A/S
(Thermex) and the Laws in force.
• Thermex disclaims any liability for damage resulting from improper
installation, assembly, operation or incorrect settings.
BEFORE INSTALLATION/OPERATION
• Check the hood for transport damage, defects and missing parts
immediately upon receipt.
• Transport damage should be reported immediately to the transport
company and Thermex upon receipt.
• Any defects and/or missing parts should be reported to Thermex
within 8 days of receipt and prior to installation/operation.
INSTALLATION
• The hood is designed to operate at 230 volts ± 10% ~ 50 Hz in ac-
cordance with EN 50160
• Connect the hood with the attached plug. NOTE: If the plug has an
Earth terminal, the hood MUST be earthed.
• For models with an external motor it is important NOT to use com-
mon zero when installing the hood and motor, as this will aect
operation.
• When using an external motor from another supplier, the motor
MUST be compatible with the selected hood. Failure to comply with
this will invalidate the warranty.
• The hood must not be connected to the mains before installation is
complete.
• The air must not be discharged from the hood into a pipe used for
extraction from devices using gas or other combustible materials.
Such devices must have a separate vent.
• The national legislation on air emissions must be observed.
• Always use the original exhaust measurements. Reduction of the
exhaust size will reduce performance and increase sound levels.
• The exhaust from the hood to the outside should be as short as
possible in order to maximise the eciency of the hood.
• The number of bends on the exhaust should be minimal in order to
maximise the eciency of the hood.
• Thermex recommends that vent hoses insulated against noise and
condensation for all bushings in unheated rooms are always used.
• Thermex recommends using a silencer when flexible hoses are used
in order to minimise sound levels.
• When using flexible hoses, always ensure that they have been fully
extended in order to minimise air resistance and thereby maximise
suction performance.
• Dierent materials require dierent rawlplugs and screws. Rawl-
plugs and screws suitable for the material onto which the hood will
be mounted on must be used.
• If the instructions for the installation of screws and fittings are not
followed, it may result in electrical shock.
• The minimum distance to gas hobs from the burner’s edge to the
underside of the hood MUST be a minimum of 65 cm in accordance
with EN 60335-2-31.
• For cupboard-integrated, suspended and wall-mounted hoods,
Thermex recommends that the distance between the hob and cook-
er hood is between 50 cm and 70 cm in order to ensure maximum
suction.
• Always check the minimum distance between the hob and the
cooker hood, as indicated in the instructions for the hob. The in-
structions for the hob MUST be observed if a greater distance than
that recommended by Thermex is indicated in this manual.
• Thermex recommends that the distance between the hob and the
hood should not exceed 3 meters for ceiling-integrated models.
ENGLISH
»
GENERAL WARNING
GENERAL WARNING
