Chart 3
0
500
1000
1500
2000
2500
0.1 1 10 100
Frequency (GHz)
Volts/Metre
Chart 3. The tested Mk2 EPDs were not susceptible to E-field radiation below the above spot frequencies
(0.1GHz - 100GHz pulsed 1kHz 1µS)
