CSR-20 & CSR-40, September 1999

Unit Description Unit Illustrations 2-7

Evaporator Section for Models with Three Evaporator Fans — Front View

1. Evaporator Fan Blade (see “Physical Specifications” on page 1-8 for description)

2. Evaporator Fan Motor

3. Return Air Sensing Bulb for Recording Thermometer (Option)

4. Return Air Sensor

5. Humidity Sensor (Option)

6. Humidity System Compressor (Option), see page 2-17

12 3 4 5 6
