on
on
Range
Capacity
Mass
Flat
25 L 45 kg
40 L 70 kg
65 L 100 kg
80 L 120 kg
100 L 140 kg
6
2.2 Horizontal wall-mounted water heater
(25/40/65/80/100 L)
IMPORTANT: The SQUARE 75/100/150 L model is
vertical
wall-mounted only
Position the drilling template (printed on the packaging) on the
wall surface and mark the points corresponding to the water
heater model, ensuring the minimum clearance spaces to be
left around the water heater are respected (see diagram E).
Drill and plug the water heater and use attachments of
at least 10 mm in diameter (Ø) suitable for your wall type
(drywall, concrete, brick).
Important: your wall must be able to bear the weight of the
water heater when lled.
Securely attach the support brackets, and use a rule to check
distances between the brackets. The elements used for
mounting must not protrude beyond the contact sur-face with
the water heater.
Lift and t your water heater against the bracket(s), taking
care to position the mountings on top of the brackets
(diagram F).
Lower the water heater until the mountings engage in
the notches. Once the mountings are engaged, it will no
PLEASE NOTE: The cold water inlet and the hot water outlet must be positioned on the left.
The hot water outlet must be positioned upward.
Diagram E
WALL
400 mm
min.
The mounting brackets do not enable any con guration other than those set out
in
this manual. Using the brackets to attach the water heater to the ceiling
is strictly
PROHIBITED.
CEILING
FLOOR
20 mm
min.
WALL
Water heater
Diagram F
Bracket
on
Water heater
Bracket
Wall
Wall
NO
on
Indicative weight
of the lled
water heater
Installation manual: General installation diagram
EN
longer be possible to slide the water heater from side to side without exerting signicant force.
YES
