This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervi-
sion or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and user mainte-
nance shall not be made by children without supervision.
It is adamant you use a low pressure valve!
Statement of conformity
NEG-Novex GmbH duly declares that the Thermoflow boiler complies with the follow-
ing directives:
• 2006/95/EC Low Voltage Directive
• 2004/108/EC Electromagnetic Compatibility Directive (EMC)
• 2011/65/EC (RoHS II)
• 2009/125/EC Eco design
• (EC) No. 814/2013
The product also conforms to the following harmonised European standards:
• EN 55014-1:2006 + A1:2009 + A2:2011
• EN 55014-2:1997 + A1:2001 + A2:2008
• EN 61000-3-2:2006 + A1:2009 + A1:2009
• EN 61000-3-3:2013
• EN 62233:2008
• EN 50581:2012
• EN 60335-1:2012 + AII:2014
• EN 60335-2-21:2003 + A1:2005 + A2:2008
22-07-2016
NEG-Novex Großhandelsgesellschaft für Elektro- und Haustechnik GmbH
Chenover Str. 5, D-67117 Limburgerhof
2. Mounting instructions
Environment
This device is delivered in sturdy packaging in order to avoid damage during transport.
This packaging consists mainly of recyclable materials. We request that you dispose of the
packaging accordingly for recycling purposes.
Disposal of the appliance
Old appliances must not be disposed of in your household waste!
Every consumer is legally obliged to dispose of old appliances separately from their house-
hold waste and to take them, for example, to a collection point in their local community or
local district. Old electrical appliances will be accepted there free of charge. This ensures
that the old appliances are properly recycled and any negative impacts on the environment
are avoided.
This is why electrical appliances are marked with the symbol shown on the left.
Installation
The device should be installed in accordance with the drawing on the first page of the
user manual. Any other installation position may result in serious damage to the device.
Installation should take place as close as possible to a cold water connection. The product
should be protected from the effects of frost (for example in caravans, summer houses, etc.).
Depending on the model, the device may be installed above (OT-model) or under (UT-
model) the work top.
Frost
If there is the risk of frost in a room, the device should not be installed
in this room. If, despite this advice, the device is installed in a room
where there is a risk of frost, the device should be emptied before
the risk arises.
Connection to the water supply
(Illustration 1.)
K = cold water entry side (for filling) blue.
W = hot water exit side (hot water demand) red.
The device is designed for use in non-pressure systems. This system allows water to be
drawn from a single discharge point. Never use a shut-off valve in the appliance’s outlet.
The connection pipes must be installed as shown in the drawing.
A low-pressure tap fitting must be used for non-pressure
installation.
It is important you are absolutely certain that the tap you want
to connect concerns a low pressure tap. If any doubt, always con-
sult your installer.
The water supply pipe and water discharge pipe are marked (red for
hot water, blue for cold water). (See the assembly instructions for the
tap fitting.)
If the mains water supply pressure exceeds 5 bars, a pressure re-
strictor must be fitted in the feed pipe. At the spout of the tap only a
strainer (supplied with tap) can be installed, whereas a normal aera-
tor or restrictor is prohibited.
Use of the latter, or usage of a tap that is not meant for low pres-
sure installations (e.g. garden hose), may cause pressure build-up
in the device that might lead to damage and thereby void the
warranty!
