Thetford C262CWE - C263 S Water Hose and Cosmetic Seal

13
C263S
6.6
6.66.6
6.6 Water hose
Water hoseWater hose
Water hose
Make sure that after routing the water hose the waste
-
holding tank still can be removed from the toile
t.
Diameter
Inside:
Outside:
10
mm
16 mm
Length
+ Position
740
mm
from the back of the toilet
Required pressure remote
pump at the toilet inlet
Min
.
0.35
b
ar at 4.2
L/min
Max. 0.70 bar at 7.1 L/min
Please meet these requirements to ensure co
rrect flush
.
6.7
6.76.7
6.7 Cosmetic w
Cosmetic wCosmetic w
Cosmetic wall seal
all sealall seal
all seal
The wall seal is integrated with the toilet.
Pay close attention to the position of the wall seal!
