10.6 Water hose
Water hoseWater hose
Water hose
The water
hose is led through the hole in the spl
ashguard. From there the water hose can be freely routed to the
left or right underneath the toilet.
Diameter
Inside:
Outside:
10
mm
16 mm
Length + Position
500
mm from the splashguard
If necessary remove a part of the
splashguard.
Required pre
ssure remote
pump at the toilet inlet
Min. 0.35 bar at 4.2
L/min
Max. 0.70 bar at 7.1 L/min
Please meet these requirements to ensure a correct flush.
10.7
10.710.7
10.7 Cosmetic w
Cosmetic wCosmetic w
Cosmetic wall seal
all sealall seal
all seal
The wall seal is integrated with the toilet.
Pay close attention to the position of the wall seal!
