Included items
Open the package and ensure that the following items are included.
External battery Charging cable for the
cigarette lighter socket
*1
Charging cable for the
fuse box
*2
Output cables
Fuse holder (3 types)
*2
Fuse (3 types)
*2
Velcro tape Quick start guide
*1. The item is included only when you purchased a product with the charging cable for the cigarette lighter
socket.
*2. The item is included only when you purchased a product with the charging cable for the fuse box.
Part names
Refer to the following gures for the location of connectors and indicators on the product.
Place velcro tape here.
Place velcro tape here.
Charging cable
connector
Power switch
Output cable
connector
Operation
indicators
