Thitronik WiPro - Page 29

Batterie
battery
+
-
COM
NO
ws w
br bn
gn gn
Zündung/ Ignition ge y
sw
rt
ws w
ws/or w/or
vt/or vo/or
rt r
rt r
sw sb
F10A
Status LED
Sirene / siren
ws/sw w/sb
rt/p r/p
Warnblinker /emergency inicator
WiPro „all in one“
Hupentaster /horn switch
sw sb
CAN-H
CAN-L
Anschluß
G.A.S.-pro
falls verwendet/
Connection to
G.A.S.-pro if
used.
Antenne. Nicht Kürzen oder aufwickeln! Antenna. Do not shorten or wind up!
Pin Nr.: 10 19 20 2 3 7 16 15 6 9 4 5 11 1 17 18
p p
bl/sw bl/sb
bl bl
Anschluß
original ZV.
Signalaus-
wertung.
Conection
to central
locking unit.
Signal inter-
pretation.
öffnen / open schliessen / close
Batterie
battery
+
-
COM
NO
ws w
br bn
gn gn
Zündung/ Ignition ge y
sw
rt
ws w
rt r
rt r
sw sb
F10A
Status LED
Sirene / siren
ws/sw w/sb
rt/p r/p
Warnblinker /emergency inicator
WiPro „all in one“
Hupentaster /horn switch
sw sb
ws/or w/or
vt/or vo/or
CAN-H
CAN-L
Anschluß
G.A.S.-pro
falls verwendet/
Connection to
G.A.S.-pro if
used.
Antenne. Nicht Kürzen oder aufwickeln! Antenna. Do not shorten or wind up!
Pin Nr.: 10 2 3 7 16 15 17 18 9 4 5 11 1 6
p p
WiPro „all in one“ Operating Instructions Page 12
Connection diagram for Ford Transit from 2006 onwards
Connection diagram for FiatDucato,CitroënJumperandPeugeotBoxerfrom2006onwards
Iveco Daily from 2006 onwards
Deadlock function
required!
