Setting up the bass drum pedal
1. Snap the two metal rods into the holes provided on the frame of the bass drum pedal.
2. Place the beater into the hole provided on the rotary head of the pedal and tighten the clamp with the drum key.
Bass drum and hi-hat
1. Place the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
2. Place the hi-hat pedal left of the bass drum pad.
Set-up and cabling
Set up the rack, the pads and the cymbals according to your needs. Finally, position the drum pedal and the hi-hat controller in
front of the rack and connect all trigger cables to the e-drum module.
Assembly
MPS-150
11
E-Drum Set
