3
Assembly
Assembling the rack
CAUTION!
Danger of cuts on hands and fingers
When plugging the connections, take care for sharp edges on the metal pipes, screws etc.
Loosen the screws of each terminal before inserting the pipes. Mount the various elements in the specified sequence. The posi‐
tions of the pads, cymbals, etc. are shown in the illustration below.
Assembly
e-drum set
6
