thomann Millenium MPS-600 Assembly Instructions

1. Put the two two-piece cymbal holder into the pipes (L1) and (R1) on the rack.
2. Place the short one-piece cymbal holder into the (from the perspective of the drummer) right unused terminal of the left
side arm.
3. Put the long one-piece cymbal holder into the unused terminal of the right side arm.
4. Unscrew the wing nuts from the cymbal holders and take the felt washer from the holders.
5. Place the four cymbals as shown in the figure on the holders.
6. Place the felt washers on the cymbals and tighten the four cymbals with the associated wing nuts on the holders.
Assembly
MPS-600
11
