1 Drumhead
Striking surface (Ø 203 mm) to play the drumhead sounds
2 Hoop
Striking area to play rim shot sounds
3 Rim knobs
To play additional sounds derived from rim shot sounds
4 Rotary control [VOLUME]
Volume control for headphones output. Turn this knob clockwise to increase the volume. Turn it counter-clockwise
to reduce it.
5 Rotary control [DIAL/ENTER]
Controller with pressure switch for patch / loop selection, for adjusting loop and effect parameters. Turning this knob
allows the selection of loop parameters and effects types. Push the knob for about 3 seconds to store the current
setting.
Operating elements
Synth Drum
11
