Mounting the drum module on the rack
1. Put the drum module up to the stop into the designated terminal of the left side arm.
2. Align the module and tighten the wing nut of the terminal.
Mounting the kick pedal
1. Snap the two metal rods into the holes provided on the frame of the pedal.
2. Place the beater into the hole provided on the rotary head of the kick drum pedal and tighten the clamp with the drum key
firmly.
Bass drum
Position the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
Assembly
MPS-600
11
