1. Connect the centre pipe (1) to the upper terminal and the centre pipe (2) to the lower terminal of the pipe (L1).
2. Roughly align the height of the terminals on pipe (L2) according to the height of their counter-terminals on pipe (L1). Con‐
nect the centre pipe (1) to the upper terminal and connect the centre pipe (2) to the lower terminal on pipe (L2).
3. Tighten the screws of the four terminals with the drum key evenly hand-tight.
4. Connect the side arm (L1) to the terminal on pipe (L2) and tighten the screws of the terminal with the drum key evenly
hand-tight.
5. Connect the side arm (R) to the terminal on pipe (R2) and tighten the screws of the terminal with the drum key evenly
hand-tight.
Assembly
MPS-600
7
