1 [HF]
Equalizer: Control for adjusting the high frequencies of each channel in a range of –15 … +15 db.
2 [LF]
Equalizer: Control for adjusting the low frequencies of each channel in a range of –15 … +15 db.
3 [FX]
Pushbutton for turning the digital effect for channels CH1 … CH4 on and off.
4 [LEVEL]
Separate volume controls for CH1 … CH7/8.
5 [MIC]
Microphone inputs of channels CH1 … CH4.
Only microphones may be connected to these inputs. When using condenser microphones, turn on phantom power
with pushbutton [PHANTOM] (7).
Connections and controls
MS 12
17
