14 [7/8]
RCA input sockets for connecting an external audio source.
[RECORD OUT]
RCA output sockets for connecting the device to an external recording device.
15 [5/6]
1/4" input sockets for connecting an external audio source. For mono operation, use the [L (MONO)] socket only.
Connections and controls
active speaker
20
