thomann the box pro DSP 108 User Manual

8 MAX INPUT 1
Rotary gain control for input 1. Turning clockwise increases the input gain for connecting microphones. Turning
counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
9 MAX INPUT 2
Rotary gain control for input 2. Turning clockwise increases the input gain for connecting microphones. Turning
counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
10 Grill
11 [POWER INPUT]
Plug for mains cable with fuse holder
12 Switch [AUTO Stand-by] (DSP 108, DSP 110, DSP 112)
Behind this opening, you nd the switch that turns the automatic shutdown function on and o. When pressed, the
function is deactivated, when not pressed, it is activated. The device will turn o after approx. 60 minutes without
input signal. When the input signal recurs, the device returns automatically.
Connections and controls
Active speaker
20
