1 [DSP]
backlit display for DSP functions
2 [INPUT 1]
Mic / Line input 1, designed as XLR / 1/4" combo socket, balanced
3 [AUX IN]
3.5 mm jack socket for connecting line level devices such as MP3 or CD players. Stereo signals are combined.
4 [OUTPUT]
Line output, designed as XLR chassis plug. The combined signal of both inputs is present here, unaected by DSP.
5 [INPUT 2]
Mic / Line input 1, designed as XLR / 1/4" combo socket, balanced
6 Vents
7 [MASTER / PUSH FOR DSP]
Rotary control for the overall volume, push button for activating the DSP functions
Connections and controls
DSP 108, 110, 112, 115
