4.2 Pin assignment
You can use XLR and 1/4" plugs with balanced or unbalanced wiring. In the following, we will
give you an overview of the various options.
XLR chassis sockets serve as signal inputs, XLR chassis plugs serve as signal outputs. Drawing
and table indicate the XLR pin assignment.
Balanced wiring:
1 Ground, shielding
2 Positive signal (+)
3 Negative signal (–)
XLR connections for signal in
and outputs
Installation
TP 108 MA
15
