1 [Power]
Mains switch to turn the device on and off.
2 [Fuse]
Fuse holder for the power supply.
If the fuse blows, replace it with a new fuse of the same type. You must first disconnect the device from the power
supply.
3 [Power]
Blue lockable powerCON input socket (NAC3FA).
4 [Right – Line Out – Left]
Line signal ouputs, designed as XLR chassis sockets.
5 [Right – Line In – Left]
Line signal inputs, designed as XLR / 1/4" chassis combo sockets.
Connections and operating elements
Miniray
19
