Thomas T-617HDN - Page 13

TANK PARTS LIST
11
46
50
45
37
41
43
42
35
36
33
34
47
48
30
49
31
44
38
39
32
40
39
Item
No.
Part No. Description Qty
30 602657 Pressure Switch 1
31 615779 Sleeve - Self Aligning 1
32 618149 Exhaust Tube 1
33 615826 Unloader Tube 1
34 624925 Fitting 1
35 617677 Drain Cock Assembly 1
36 624361 Elbow - Unloader Tube 1
37 624654 Bumper 1
38 624510 Insert-Unloader Tube 2
39 624511 Insert-Exhaust Tube 1
Item
No.
Part No. Description Qty
40 624517 Connector - Head 1
41 625206 Screw-Cprsr. Mounting 4
42 626563 Washer- Cprsr. Mounting 4
43 626509 Lock Washer-Cprsr. Mtng. 4
44 626766 Nut - Compression 1
45 625406 Screw - Bumper 4
46 633660 Cord 1
47 633957 Safety Valve 1
48 638262 Gauge - Pressure 1
49 638322 Check Valve Assembly 1
50 669470-540 Tank Assembly 1
