TRAD 350 SO DIGIT
5.2 - Vice
- Material clamping system during the cutting operation by
means of an approach handwheel and hydraulic clamping. .
NOTE: since standards and legislation concerning refuse in gen-
eral is in a state of continuous evolution and therefore
subject to changes and variations, the user must keep
informed of the regulations in force at the time of dis-
posing of the machine tool, as these may differ from
those described above, which are to be considered as
a general guide line.
MACHINE FUNCTIONAL
PARTS
5.1 - Operating head or saw frame
- Part of the machine consisting of drive members (gearmotor
or variable speed motor, flywheels), tightening and guide (blade
tightening slide, blade guide head) of tool.
5
5.3 - Bed
- Structure supporting the SAW FRAME OPERATING HEAD
(revolving arm for degree cutting along with clamping sys-
tem), the VICE, the BAR STOP, the ROLLER for the support
of the mateial. The bedplate houses the cooling liquid TANK,
the CONTROL BOARD, ELECTRICAL PART and the DEVICE
CONTROLLING THE AUTOMATIC HYDRAULIC LOWER-
ING AND RISE OF THE SAW FRAME.
