Thomas&Betts TBM14MC - Parts List For Type 2

TA02982 E page 5 of 8
4.0 PARTS LIST For Type 2
See Figure 5 for complete tool assembly.
Code N° Item Description Qty
6800040 1
RESERVOIR CAP
1
6720100 3
OIL RESERVOIR
1
6360260 8
O-RING
1
K
6040685 8
GUIDING RING
2
6900621 9
SUCTION SCREW
1
6360160 10
O-RING
2
K
6740060 11
BALL
2
K
6520765 12
SPRING
2
K
6160044 13
TOOL BODY
1
6740140 14
BALL
2
K
6520180 15
SPRING
2
K
6340566 16
DOWEL
2
6900059 17
SCREW M4x8
2
6100037 18
KEY
1
6900211 27
SCREW M5x10
1
6100035 28
KEY
1
6340540 34
GRUB SCREW
1
6362035 38
SEAL
1
K
6362010 39
SEAL
1
K
6641140 40
BACK-UP RING
1
K
6360240 41
O-RING
1
K
6362020 42
SEAL
1
K
6620382 43
PUMPING RAM
1
6700100 46
CIRCLIP
4
K
6560420 48
PIN
2
6600101 53
SPRING COVER
1
K
6520862 54
SPRING
1
K
6640205 55
WASHER
2
6900080 56
SCREW M4x8
1
6340720 57
GRUB SCREW
1
6520861 58
SPRING
1
6635011 59
PIN
1
6895050 60
COMPLETE VALVE
1
6740120 61
BALL
1
K
6600100 62
BALL SUPPORT
1
6520260 63
SPRING
1
6740080 64
BALL
1
K
6620120 65
PIN
1
6360120 66
O-RING
1
K
Code N° Item Description Qty
6040060 67 BACK-UP RING 1
K
6080080 68 BUSH 1
6232589 77 TA04568 LABEL 1
6170143 88 PLASTIC CAP 2
6480407
200
COMPLETE MAIN
HANDLE
1
6380265
200 2 HANDLE GRIP 1
6370238
201
COMPLETE
INSULATED HEAD
1
6620245
201 30 PIN 1
6760160
201 31 PIN 1
6620440
201 32 PIN 1
6522006
201 33 SPRING 1
6340540
201 34 GRUB SCREW 1
6800088
201 75 PLASTIC CAP 1
6620250
201 76 PLASTIC CAP 1
6620312
202 COMPLETE RAM 1
6700250
202 19 CIRCLIP 1
6170140
202 20 COVER 1
6362058
202 21 SEAL 1
K
6040128
202 22 BACK-UP RING 1
K
6520619
202 23 SPRING 1
6520611
202 24 SPRING 1
6300079
202 25 RAM GUIDE 1
6522006
202 33 SPRING 1
6760040
202 35 PIN 2
6620445
202 36 PIN 1
6620320
202 37 PIN 1
6480196
203
COMPLETE
MOVEABLE HANDLE
1
6760320
203 44 SPLIT PIN 1
6200032
203 49 LATCH 1
6760280
203 50 SPLIT PIN 1
6480269
203 51 MOVEABLE HANDLE 1
6380240
203 52
MOVEABLE HANDLE
GRIP
1
6900280
203 69 SCREW M5x18 1
6180200
203 70 NUT 1
The warranty is void if parts used are not original Thomas & Betts parts.
When ordering spare parts always specify the following:
− Code Number of Item
− Name of Item
− Type of Tool
− Tool Serial Number
The items marked with (K) are those that Thomas & Betts
recommends replacing if the tool is disassembled.
These items are supplied on request in the
“TBM14MC Spare Parts Package”
