Cleaning and replacing the multi-stage air filter
1. Unplug the appliance.
2. Remove the water tank. (fig. 1)
3. Empty the humidifier chamber and
wipe it off with a soft napkin.
4. Turn the enclosure over and place
it on a flat surface.
5. Unscrew the bottom cover fixing
screw by turning it anticlockwise
(fig. 2) and remove the bottom
cover.
6. Remove the multi-stage air filter.
Replace or clean it if heavily soiled.
(fig. 3)
Carbon filter
Absorbs fine dust particles,
unpleasant odors, aerosols,
combustion products and
gas mixtures.
HEPA H13
Purifies the air by 99.95%,
trapping particles down to
0.06 microns.
Pre-filter
Removes coarse dust
and debris from the air,
extending the lifespan of
the HEPA filter.
(fig. 1)
(fig. 2)
(fig. 3)
37Air complex
