1 SpeedTouch™190 Installation
E-DOC-CTC-20040401-0004 v1.0
7
Back panel layout
WAN Green On Ethernet connectivity to the Internet
Gateway Device
Off No Ethernet connectivity to the
Internet Gateway Device
TEL Green On Phone off hook
Off Phone on hook
Indicator Description
Name Color State
A TEL port D Recessed Reset button
B WAN port E Power inlet
CLAN port
A B D EC
