1 SpeedTouch™190 Installation
E-DOC-CTC-20040401-0004 v1.0
8
1.2 Setting Up the SpeedTouch™190
Connect the VOIP line Plug the telephone cable (RJ11) provided into the SpeedTouch™190’s VOIP socket. Plug
the other end into your telephone’s RJ11 line socket.
Connect the LAN line Use an Ethernet cable to wire the SpeedTouch™190 LAN port to your PC’s Ethernet
card.
Connect the WAN line Use the Ethernet cable provided to wire the SpeedTouch™190 WAN port to your
Internet Gateway Device.
Connect the power
supply
Always check first whether the power supply adapter provided is suitable for the local
power specifications. Contact your product dealer in case of any doubt.
The power inlet on the SpeedTouch™190 is marked “12V AC”.
Plug the adapter’s coaxial jack into the SpeedTouch™190’s power inlet and plug the
power supply into a power socket outlet.
The SpeedTouch™190 is ready for service as soon as the Power LED on the front panel
is constantly lit green.
