9
41-54or 12-20℃(54-68℉))
- You switch the appliance on, if the temperature inside the appliance is very different (+/-
4) from the temperature set after hours working
- Too many items have been put into the unit at one time, and the temperature inside the
appliance is very different (+/-439℉)) from the temperature set after 7 hours working.
- The door has not been closed tightly.
Door alarm
If the door has been left open for more than 60s, the alarm will sound. Once set
temperature has been reach in the appliance, the alarm stops and the relevant
temperature display stops flashing.
However, if the noise disturbs you, you can switch the alarm off before this if you wish by
pressing the key “I” once, The alarm will stop. The relevant temperature display continues
to flash until the set temperature has been reached. The display then lights up constantly
and the alarm system is fully active again.
Interior light
The interior light makes it easy to view your wines labels and enhances the display of your
collection. Touching the mark (J) toggles between modes of operation for interior
lights:
- Functional mode (default): the lights will turn on only when door is open, this is the most
economic mode
- Showcase mode: the lights will be on whether or not the door is open. To turn this
permanent light mode and get back the default mode, please push again the light button
(J)
- The interior light can be changed the color by manual switch.The light switch positions
are like below pictureunder the control panel showed to control the color turn on/off.
1 Original color; Blue color
When turn on the original and blue color switch at the same time,the color vary by optical
action.
Dynamic climate / silent mode
Wine cellars are designed to preserve your wines in perfect conditions over long periods
in complete safety. However, no frost systems can cause noise, this is the reason why the
