THOR MOTOR COACH
CONTROLS AND OPERATIONS
36
ADJUSTING THE CLOCK (DISP): The current time is displayed in the top right hand corner of the LCD
display. To adjust the clock:
1. Press and hold the MENU button (3) to view the System Setup menu.
2. Touch the “Clock” field to view the clock set screen:
3. Use the on-screen touch pad to enter 4 digits representing the time.
4. Touch the “AM/PM” field to toggle between AM/PM, if necessary.
RESET:
Use a ball point pin or thin metal object to press the RESET button (2). The reset button should be
activated for the following reasons:
• initial installation of the unit when all wiring is completed
• function buttons do not operate
• error symbol on the display
AUDIO MENU:
Press the MENU button (3) on the control panel to access the User Settings Menu.
Each level adjustment is indicated as a horizontal bar graph and an associated numbered level
setting. Adjustments are made by pressing virtual buttons at the end points of the bar graph.
The following menu items can be adjusted:
BASS LEVEL:
Use the volume control to adjust the Base from -6 to +6.
TREBLE LEVEL:
Use the volume control to adjust the Treble level range from -6 to +6.
BALANCE:
Use the volume control to adjust the Balance between the left and right speakers from 12L (full left) to 12F
(full front).
FADER: Use the volume control to adjust the Fader between the rear and front speakers from 12L (full left)
to 12F (full front).
VOLUME LEVEL: Use the volume control to adjust the volume level from 0 to 46.
