THOR MOTOR COACH
CONTROLS AND OPERATIONS
46
Space Saver Sofa
SOFA TO SLEEPER
• Unlatch and remove sofa arms ( if equipped).
• Raise the sofa seat base until the seat base and backrest form a “V” shape by lifting up from
the center of the sofa just below the seat cushions.
• Pull out and push down on the seat base until the seat base is flat.
• Fold the seat belts out of the way.
SLEEPER TO SOFA
• Lift the seat base up until the seat and back rest from a “V” shape.
• Push back and down on the seat base.
• Position the seat belts for use.
• Replace the back rest cushions.
Hide-A-Bed Sofa
SOFA TO SLEEPER
• Grasp the front metal bar and lift up, pulling out on the bar slightly until the leg of the bed is
resting on the floor.
• Fold the seat belts out of the way.
• When the legs of the bed are on the floor another lifting bar will be exposed, grasping and
pulling the lift bar will open the bed fully.
SLEEPER TO SOFA
• Remove all bedding from the hide-a-bed.
• Grasping the foot of the hide-a-bed in the center using the metal lifting bar, lift the front portion
of the lifting bar to raise and then lower the hide-a-bed back into the sofa base.
• Position the seat belts for use.
• Replace the seat cushions.
Air Hide-A-Bed Sofa ( Drawer Storage Below)
• Pull back rest section of sofa out and over seat cushions.
• Fold legs up.
• Rotate till legs rest on floor.
• Unfold air mattress, plug in, fill with air.
Note: Do not fold the air mattress up in the sofa. Damage will occur.
Air Hide-A-Bed ( No Drawer Storage Below)
• Remove back rest cushions.
• Pull seat cushion section up and out
• Rotate bottom of seat cushion out and fold legs down.
• Fold back rest down to create platform.
• Unfold air mattress, plug in, fill with air.
Note: Do not fold the air mattress up in the sofa. Damage will occur.
Barrel Chair
The barrel chair has controls on the bottom right and left sides under the chair skirt that controls the swivel
and side to side action of the chair.
