Average Reflectance 80% (Typical)
Phase / Retardance Range
a
2π at 633 nm (Full Wave Mode)
π at 633 nm (Half Wave Mode)
2π at 1064 nm (Full Wave Mode)
π at 1064 nm (Half Wave Mode)
Angle of Incidence
b
0°
Optic Axis 0°
Reflected Wavefront Distortion <λ/2 @ 633 nm <0.4λ @ 633 nm
Frame Rate 60 Hz
Optical Power Handling
c
≤200 W/cm
Damage Threshold
Pulsed (ns)
0.22 J/cm
2
(532 nm, 6.8 ns, 10 Hz, Ø200.5 µm)
0.15 J/cm
2
(1064 nm, 10 ns, 100 Hz, Ø235
µm)
Pulsed (fs)
0.0935 J/cm
2
(515 nm, 203.3 ns, 100 Hz, Ø108.2
µm)
0.03 J/cm
2
(1030 nm, 200 fs, 100 Hz, Ø135
µm)
Fluctuation / Flickering (RMS)
d
<0.01% <0.15%
Beam Deviation Using Panel Tip /
Tilt
N/A
Trigger Output
e
SMA Female
Trigger Output High Voltage
Level
5
V (TTL)
Trigger Output Pulse Width 54
µs
Connector Type (for Tubing)
CPC
®
Valved Thumb Latch Quick-Disconnect Fitting
Tubing Dimensions
0.17" (4.3 mm) Inner Diameter (Pre-Installed)
0.24" (6 mm) Inner Diameter (Optional)
Dimensions (L x W x H)
220.0 mm x 104.0 mm x 68.0 mm
(8.66" x 4.09" x 2.68") All-in-One Mode
420.0 mm x 104.0 mm x 42.0 mm (16.54" x 4.09" x 1.65") Separate-
Panel Mode
Weight 0.7 kg (1.54 lbs)
Storage Temperature 0 °C to 60 °C (32 °F to 140 °F)
Operating Temperature
e
10 °C to 40 °C (50 °F to 104 °F)
PC Connection
HDMI-Compatible Connector
USB 2.0 Connector
Bit Depth 8 Bit, 0 - 255 Gray Level
SLM Head Thermistor
Type
VISHAY NTC LE413 (R
0
= 10 kΩ @ T
0
= 25 °C, B = 3435 K)
Accuracy ±0.5 °C (@ 25 °C)
a. Phase/retardance range values are for 30 °C when used with the LK220 liquid chiller.
b. Other angles of incidence will result in phase shifts that differ from the programmed pattern. Angles of
up to 10° are possible without significantly affecting performance.
c. Specification with the LK220 Liquid Chiller
d. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is
dependent on current phase setting. The value stated is the maximum fluctuation and typically occurs at
half of the phase range.
e. For more details on the external trigger output, please refer to the product manuals accessible through
the red Docs ( ) icons below.
f. Ambient temperature fluctuations may cause the characteristics of your SLM to change. Using it at an
ambient temperature of 25 °C is recommended.
Item # EXULUS-4K1(/M)
Panel Resolution 3840 x 2160 (4K UHD)
Type Liquid Crystal on Silicon (LCoS) with Reflective Coating
Operating Wavelength 400 - 850 nm
Panel Active Area 15.6 mm x 9.2 mm
