Frame Tab in Standard Frame Rate Mode:
Setting a specific gray level from 0 to 255 will set
the entire panel to a certain phase level.
"Spatial Light Modulator" Software Package for EXULUS-HD1 and EXULUS-4K1
Each Exulus
®
SLM comes with a software interface that provides complete control of the SLM panel as well as
device settings. Users can input a specific phase level (gray level) over the entire panel, import a custom image,
produce a computer generated holography (CGH) pattern, and other patterns such as Fresnel lenses and
diffraction gratings. All the patterns can be saved into a sequence list and played with a predefined interval of
16.7 ms (60 Hz frame rate, EXULUS-HD1, EXULUS-HD2, EXULUS-HD3, EXULUS-HD4, EXULUS-HD2HP, and
EXULUS-HD3HP) or 33.3 ms (30 Hz, EXULUS-4K1) in standard mode. The EXULUS-HD1 also features a triple
mode; if RGB images are used then the RGB channels will be played in succession for an overall frame rate of
180 Hz. The software also supports video input at 1080p or 4K resolution with the H.264 video codec (supported
file formats: MP4, M4V, and MOV).
Note: There are two separate software packages for our Exulus spatial light modulators:
The "Spatial Light Modulator" software package is designed for use with our EXULUS-HD1 and EXULUS-
4K1 SLMs.
The "Thorlabs EXULUS" software package is designed for use with our EXULUS-HD2, EXULUS-HD3,
EXULUS-HD4, EXULUS-HD2HP, and EXULUS-HD3HP SLMs.
Click the yellow bars below for screenshots highlighting various software features and capabilities:
SOFTWARE
Software
"Spatial Light Modulator" Software
Version 1.0.12
This software package is designed for use
with our EXULUS-HD1 and EXULUS-4K1
SLMs.
"Thorlabs EXULUS" Software Version
2.5.1
This software package is designed for use
with our EXULUS-HD2, EXULUS-HD3,
EXULUS-HD4, EXULUS-HD2HP, and
EXULUS-HD3HP SLMs.
Click the button below to visit the software
page.
