ThoroughClean D10M-36H - Page 2

2
D10M-36H D10M-36H-BB
D10M-36H-BBO
‘O’ = Oval tank
D10M-36H-T
D10M-36H-TO
‘O’ = Oval tank
D10M-36H-TD
‘D’ = Double Axle
Build Spec Mine Mine Mine Mine
Boiler & Temp
Diesel - 70ºC.
21 lit. fuel tank
Diesel - 70ºC.
21 lit. fuel tank
Diesel - 70ºC.
21 lit. fuel tank
Diesel - 70ºC.
21 lit. fuel tank
Frame Type Skid Skid with 1000 litre
tank
Trailer with 1000
litre tank
Trailer with 2000
litre tank
Engine KOHLER 10.3 hp KOHLER 10.3 hp KOHLER 10.3 hp KOHLER 10.3 hp
Model KD440 – 1 Cylinder
Air cooled, 442 cc
KD440 – 1 Cylinder
Air cooled, 442 cc
KD440 – 1 Cylinder
Air cooled, 442 cc
KD440 – 1 Cylinder
Air cooled, 442 cc
Start Electric + recoil Electric + recoil Electric + recoil Electric + recoil
Gearbox 2:1 reduction 2:1 reduction 2:1 reduction 2:1 reduction
Battery
• • • •
Battery Box
• • •
New HAWK Pump
Model
NPM1525R NPM1525R NPM1525R NPM1525R
Old HAWK pump
model
HC456 HC456 HC456 HC456
Max Pressure &
Flow
3625 psi 15 lpm 3625 psi 15 lpm 3625 psi 15 lpm 3625 psi 15 lpm
Set-up / de-rated
pressure & flow
3000 psi 15 lpm 3000 psi 15 lpm 3000 psi 15 lpm 3000 psi 15 lpm
Nozzle size at set-
up pressure
#15045 #15045 #15045 #15045
Pump Speed RPM
1450 1450 1450 1450
Hour Meter
• • • •
Engine-Pump
vibe-mounted
• • • •
Slave Oil Tank to
pump
• • • •
S/steel Water
Break Tank
• (if required)
Low water engine
shut-down
• (if required)
• • •
Soft-acting By-
pass Valve
• • • •
Thermoshield
Protection
•
Built-in Reel
• (Optional
without)
• • •
Hose length 30m 30m 30m 30m
Water Tank 1000 lit. IBC
1000 lit. Poly
1000 lit. IBC
1000 lit. Poly
2000 lit. IBC
2000 lit. Poly
Ind. Water Filter
•
• (double) • (double) • (double)
Gun & 900 mm
s/steel lance
• • • •
Weight: 335 kg ~400 kg (tbc) ~600kg / ~650kg ~1,100 kg (tbc)
Size (L x W x H)
cm
133 x 71 x 150
224 x 122 x 140
274 x 122 x 110
3.6 x 1.85 x 1.8
4.1 x 1.85 x 1.5
TBC
Mine Spec
Features
As Specified As Specified As Specified As Specified
